Vollrath 3665120HD Steam Tables & Food Wells

Product Description

The Vollrath Model 3665120HD drop-in unit is designed to create a space-saving and customer-friendly serving line without sacrificing holding power. By rotating four full-size pans sideways, this unit keeps hot entrées within easy reach while reducing the needed countertop depth, making it ideal for cafés, colleges, and concession venues where every inch of space counts. Featuring infinite controls and a manifold drain, this 208-240V 1-phase unit is designed for wet (steam-table) operation, so it is important to always keep water in the wells during use for even heat distribution.

Why You'll Love It:

  • The side-oriented wells have a slim 18-inch frontage, allowing for tighter counters and faster service.
  • The 18-gauge, 316 marine-grade stainless-steel wells are resistant to chloride corrosion from salted or acidic foods.
  • The individual infinite controls with pilot lights let you easily adjust and monitor the holding temperatures.
  • The 1-inch copper manifold drain with a master shut-off valve simplifies the process of removing water between services.
  • The thick polyurethane foam insulation on every side and between the wells maximizes energy efficiency.
  • The full-perimeter drip edge and included drain plug help keep the countertops spotless.
  • It ships with a 6-foot cord and a NEMA 6-30P plug, so no hard-wiring is required.
  • It is made in the USA and listed to UL, cUL, and NSF standards, providing peace of mind.

Built to Last:

  • The wells are made in one piece, which prevents food from getting trapped in welded seams, ensuring superior sanitation.
  • The stainless-steel exterior housing and remote control panel (4 ft tethered) are built to withstand daily use.
  • The standard mounting clips fit counters up to 3 inches thick, and the zero-clearance installation saves time during the setup process.

Product Specs

Specification Value
Capacity 4 full-size pans (turned sideways) or fractional equivalents
Total Power 4000 W (1000 W per well)
Electrical 208-240 V / 60 Hz / 1-phase, 14.4 – 16.7 A, NEMA 6-30P
Control Type Individual infinite switches with power indicators
Well Dimensions 20 in. × 12 in.; 8 in. deep
Overall Dimensions 88 ¼ in. L × 18 in. W
Countertop Cut-out 87 ½ in. L × 17 ¼ in. W;7⁄8 in. corner radius
Drain 1 in. copper manifold with master valve; ½ in. individual ball valves
Certifications UL, cUL, NSF
Country of Origin United States of America

Features

Specification Value
Manufacturer Vollrath
Certifications NSF, UL, Made in USA
Height 21.5in
Width 88.56in
Depth 18.0in
Shipping Weight 218.0lbs
Pan Capacity (4) full size (12" x 20")
Controls infinite controls
Style individual pans
Construction stainless steel construction
Drain with drain
Insulated or Non-Insulated insulated
Wet or Dry operation wet
Specifications Short Sided Hot Well, Drop-In, (4) pan, infinite controls, manifold drain, 4000 watts, 208-240v/60/1-ph, 14.4-16.7 amps, NEMA 6-30P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy)
NSF
NSFNSF Certified – This product meets NSF International food safety and sanitation standards for commercial foodservice equipment.
UL
ULUL Listed – This product has been independently safety tested and certified by Underwriters Laboratories.
Made in USA
Made in USAMade in USA – This product is manufactured in the United States of America.
