Vollrath 36651HD Steam Tables & Food Wells
Product Description
Designed for buffet lines, cafeterias, and serving counters with limited depth, this Vollrath Short-Side Modular Hot Drop-In maintains safe serving temperatures for four full-size pans of entrees or sides. Its corrosion-proof marine-grade wells and energy-efficient construction make it a dependable long-term investment. The unit features rotated full-size wells, infinite controls, and 208-240V, 4,000W power, providing guests and staff with an easier reach to the food.
Key Features:
- The wells are rotated to the side, which reduces the counter depth to just 18" for a compact footprint. The pans are 12" x 20" in size.
- The 18-gauge stainless-steel top is made of marine-grade SAE 316 material, providing superior resistance to corrosion from salt, steam, and chemicals.
- The individual infinite controls with power lights are on a stainless-steel remote panel (4-foot tether), allowing for flexible mounting.
- Each well has a standard ½-inch drain with ball valves and an included plug, making daily cleanup quick and easy.
- The thick polyurethane foam insulation on all sides, including between the wells, enhances temperature stability and energy efficiency.
- The full-perimeter drip edge and supplied gasket help keep condensation and spills off your countertop.
- The unit ships ready to install, with a zero-clearance top mount, mounting clips for counters up to 3 inches thick, and a 6-foot cord with a NEMA 6-30P plug.
- The product is UL, CUL, and NSF listed, and it is engineered and manufactured in the USA with a two-year limited warranty.
Product Specs
| Specification | Value |
|---|---|
| Model | 36651HD |
| Pan Capacity | 4 full-size (12" × 20") pans, up to 6" deepAdapter bars recommended for fractional pans. |
| Control Type | Individual infinite controls |
| Total Wattage | 4,000 W (1,000 W per well) |
| Electrical | 208-240 V / 60 Hz / 1-ph · 14.4 – 16.7 A · NEMA 6-30P |
| Overall Dimensions | 88 1/4" L × 18" W (224 × 45.7 cm) |
| Cutout Dimensions | 87 1/2" L × 17 1/4" W (222.3 × 43.8 cm) · 7/8" corner radius |
| Well Size | 20" × 12" each · 8" deep |
| Construction | 316 marine-grade stainless wells & 18 ga top, stainless exterior housing |
| Drain | ½" drains with individual ball valves (plug included) |
| Insulation | Polyurethane foam on all non-exposed sides |
| Agency Listings | UL, CUL, NSF |
| Origin | Made in USA |
Features
| Specification | Value |
|---|---|
| Manufacturer | Vollrath |
| Certifications | NSF, UL, Made in USA |
| Height | 15.0in |
| Width | 88.56in |
| Depth | 18.0in |
| Shipping Weight | 150.0lbs |
| Controls | infinite controls |
| Pan Capacity | (4) full size (12" x 20") |
| Style | individual pans |
| Construction | stainless steel construction |
| Drain | with drain |
| Insulated or Non-Insulated | insulated |
| Wet or Dry operation | wet |
| Specifications | Short Sided Hot Well, Drop-In, (4) pan, infinite controls, standard drains, 4000 watts, 208-240v/60/1-ph, 14.4-16.7 amps, NEMA 6-30P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy) |
