Descripción
American Range AR-24G-8B-DSB Gas Ranges
Product Description
Model AR-24G-8B-DSB | Made in USA
This 72-inch American Range gas restaurant range offers powerhouse versatility for your cookline. Its heavy-duty 24-inch griddle teams up with eight high-performance open burners, while twin 26-and-a-half-inch storage bases keep sheet pans and smallwares within arm's reach. Crafted from rugged, stainless-steel and certified for the demands of commercial kitchens, this range delivers the performance and durability your operation requires.
Key Features:
- The griddle is 24 inches wide and has manual controls. It is made from a 1-inch thick polished steel plate, which allows for fast heat recovery and even heat distribution.
- There are eight lift-off open burners, each rated at 32,000 BTU/hr. The 12-inch by 12-inch cast-iron top grates can be removed for easy cleaning.
- The unit has two 26.5-inch insulated storage bases, which provide convenient under-counter storage for equipment or sheet pans (there are no ovens).
- The stainless steel front, sides, and 6-inch deep front landing ledge are durable and easy to wipe down.
- The flue system can be chosen from three options: a 6-inch stub back, a 20-inch riser, or a high shelf and riser. Specify the desired option when ordering.
- The 6-inch chrome-plated adjustable legs allow the unit to be leveled on any surface and set the cooking height to a comfortable 36 inches.
- The rear ¾-inch NPT gas connection comes with a factory pressure regulator for easy installation.
- The unit is cETLus and ETL-Sanitation listed, and the construction is NSF-compliant for food service safety.
Perfect For:
- Businesses that serve a large number of customers, such as restaurants and diners.
- Kitchens in hotels, resorts, and casinos.
- Catering companies and ghost kitchens.
- University and corporate food service operations.
Product Specs
| Specification | Value |
|---|---|
| Overall width | 72" (1829 mm) |
| Overall depth | 32-1/2" (825 mm) |
| Cooking height | 36" (914 mm) |
| Griddle size | 24" W × 24" D × 1" thick (610 × 610 × 25 mm) |
| Griddle burners | 2 × 20,000 BTU/hr (11.7 kW) |
| Open burners | 8 × 32,000 BTU/hr (75 kW) |
| Total input | 296,000 BTU/hr (87.0 kW) |
| Gas type | Natural or LP (specify when ordering) |
| Manifold pressure | NG 5.0" W.C. / LP 10.0" W.C. |
| Gas inlet size | ¾" NPT (19 mm) |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 2-year parts & labor; 90-day replacement parts |
| Manufactured | North Las Vegas, NV & Pacoima, CA, USA |
Features
| Specification | Value |
|---|---|
| Manufacturer | American Range |
| Certifications | cETLus, ETL-Sanitation, Made in USA |
| Height | 56.0in |
| Width | 72.0in |
| Depth | 32.25in |
| Shipping Weight | 670.0lbs |
| Plate Thickness | 1.000" = 1" |
| Vent | backriser with hi-shelf |
| Base | (2) cabinets |
| Exterior Finish | stainless steel front & sides |
| Top | (8) open burners, (1) 24" griddle |
| Specifications | Restaurant Range, gas, 72", (1) 24" griddle on left, 1" thick plate, manual controls, (8) 32,000 BTU open burners, (2) 26-1/2" storage bases, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 87.0kW, 296,000 BTU, cETLus, ETL-Sanitation, Made in USA |
