Descripción
Delfield N8168NBP Steam Tables & Food Wells
Product Description
The Delfield N8168NBP is an NSF-7 certified, mechanically cooled drop-in unit that can safely and effectively chill and display your ingredients. Measuring 67-1/2" wide and 18" deep, this self-contained appliance can hold three full-size pans at a perfect temperature of 33-41°F (1-5°C), even in kitchens up to 86°F.
Key Features:
- Fits 3 pans of size 12" x 20" and 4" or 6" deep (pans not included).
- Has an integral stainless steel pan rest with V-stamped design, eliminating the need for loose screws or clips.
- Uses eco-friendly GreenGenius™ refrigeration with R290 hydrocarbon and an energy-efficient 1/6 HP compressor.
- Comes with a factory-installed press-fit gasket for quick and easy installation.
- Features high-density, zero-ODP polyurethane insulation to lock in cold and reduce energy usage.
- Includes electronic temperature control with a standby mode for overnight energy savings.
- Has a 1-inch diameter drain for fast drainage of melt-water or easy cleaning.
- Comes with a stainless steel front louver to ensure proper airflow.
- Is UL, cULus, and NSF listed for safe open food storage.
What's in the box:
- Four stainless steel adapter bars to fit 12-inch by 20-inch pans
- Pre-installed perimeter gasket
- Stainless steel front louver
- Instructions manual for installation and operation
Product Specs
| Specification | Value |
|---|---|
| Model | N8168NBP |
| Pan capacity | (3) full-size 12" × 20" pans, 4" or 6" deep |
| Overall dimensions | 67.5" W × 18" D (countertop footprint) |
| Required cut-out | 66.5" W × 17" D |
| Well recess | 2" below top surface |
| Temperature holding | 33-41°F at 86°F ambient (NSF-7) |
| Refrigeration | Self-contained, R290; 1/6 HP; 522 BTU load / 876 BTU system |
| Electrical | 115 V / 60 Hz / 1 Ph • 2 A • 8' cord with NEMA 5-15P |
| Drain | 1" I.D. plastic drain with threaded plug |
| Construction | 20-ga stainless top, 22-ga stainless liner, galvanized exterior body |
| Shipping weight | 240 lb / 109 kg |
| Warranty | 1-year parts & labor |
| Certifications | UL, cULus, NSF |
Features
| Specification | Value |
|---|---|
| Manufacturer | Delfield |
| Certifications | NSF, UL |
| Height | 21.81in |
| Width | 67.5in |
| Depth | 18.0in |
| Shipping Weight | 240.0lbs |
| Layout | narrow |
| Style | self-contained refrigeration |
| Finish | galvanized steel outer liner |
| Pan Size | full-size (12" x 20") |
| Pan Qty | 3-pan |
| Width (side - side) | 67 - 72 inches |
| Insulation | insulated |
| Specifications | Narrow Drop-In Cold Food Unit, refrigerated, 67-1/2" W, 18" D, 3-pan size, 4" or 6" deep pans, 1" drain, insulated pan, stainless steel inner liner & top, galvanized steel outer liner, self-contained refrigeration, R290 Hydrocarbon refrigerant, 1/6 HP, (66-1/2" x 17" cutout required), cUL, UL, NSF |
