Advance Tabco DTS-U30-96L Compartment Sinks
Product Description
Designed for high-volume dish rooms, this commercial-grade U-shaped soil table allows a single operator to scrape, rinse, and load dishes in one efficient workspace before sliding them directly into the dish machine. Crafted with durable 14-gauge type 304 stainless steel, this robust table is built to withstand the demands of a busy commercial kitchen and is fully NSF certified.
Top Features:
- The top is made of 14-gauge type 304 stainless steel with satin-polished TIG welds.
- The backsplash is 10-1/2 inches high and has a bold design, with a 2-inch return and a tile edge for a watertight, easy-to-flash-in installation.
- The pre-rinse sink bowl is 20 inches by 20 inches by 8 inches, and it comes complete with a basket strainer and slide bar*.
- The dish-landing shelf is 9-3/8 inches deep, allowing full racks to be kept within easy reach.
- The legs are made of 16-gauge type 304 stainless steel, with front-to-back cross-rails for extra rigidity.
- Adjustable stainless steel bullet feet allow the unit to be leveled on uneven floors.
- The unit is delivered in two sections, with a K-57 welded field joint (included) to ensure a seamless top once installed.
- All welds are blended to match the adjacent surfaces, creating a clean, professional look.
What's in the Box:
- Two U-shaped dishtable sections
- A K-57 welded field joint kit for assembling the dishtable sections
- A 20-inch by 20-inch by 8-inch sink bowl with a basket for catching food scraps
- A slide bar to hold the prerinse basket, which is used for rinsing dishes
- A 1-1/2-inch IPS basket waste drain for removing water and food waste from the sink
- Stainless steel adjustable bullet feet to level and support the dishtable
Product Specs
| Specification | Value |
|---|---|
| Overall footprint | 108" W × 59" D × 37" H (working height) |
| Inside “L” dimension | 95" |
| Sink bowl size | 20" W × 20" D × 8" H |
| Backsplash | 10-1/2" H with 2" return, tile edge |
| Gauge / material | 14 ga. 304 SS top • 16 ga. 304 SS legs & cross-rails |
| Drain | 1-1/2" I.P.S. basket-type waste (included) |
| Faucet holes | 8" on-center (faucet sold separately) |
| Orientation | Mounts to left side of dish machine operator |
| Shipping weight | Approx. 525 lb |
Features
| Specification | Value |
|---|---|
| Manufacturer | Advance Tabco |
| Height | 44.5in |
| Width | 108.0in |
| Depth | 96.0in |
| Shipping Weight | 490.0lbs |
| Shape | u-shaped |
| Stainless Series | 300 series |
| Splash Height | 10"H splash |
| Width (side - side) OA | 97" - 108" |
| Direction | left to right |
| Leg Type | stainless steel legs |
| Stainless Gauge | 14 gauge |
| Specifications | Dishtable, soiled, u-shaped, attaches to left of dish machine operator, 59" x 108" x 95" with landing, 10-1/2"H backsplash, with pre-rinse sink, 16/304 stainless steel legs with crossrails front-to-back, 14/304 stainless steel, stainless steel bullet feet, Includes prerinse basket with slide bar (slide bar only when K-461 or K-461A disposer adapter is specified) (NOTE: this dish table supplied in two pieces with a K-57 welded field joint included in the cost - field welding by others) |
