Description
American Range AR-4-SB Gas Ranges
Product Description
The American Range AR-4-SB is a powerful and compact commercial-grade cooking appliance. Featuring four high-performance open burners and a 20-inch storage base, this unit is designed for demanding kitchen environments that require both power and a small footprint. Boasting a total BTU output of 100,000, the AR-4-SB provides the heating capacity needed for busy commercial kitchens, all while being proudly manufactured in the USA.
Key Features:
- The range has 4 cast-iron open burners that can each reach up to 32,000 BTU, allowing for quick boiling, steady sautéing, and low-heat simmering.
- The 20-inch storage cabinet provides space to store sheet pans, stock pots, or cleaning supplies within easy reach.
- The stainless steel front, sides, landing ledge, and removable full-width drip pan are durable and easy to clean.
- You can choose between a 6-inch stub back, 20-inch riser, or 20-inch riser with an integrated high shelf for the backsplash, at no extra cost.
- The 6-inch chrome-plated adjustable legs level the range on uneven floors and provide a comfortable 36-inch cooking height.
- The range is field-convertible for use with either Natural or Propane gas (specify when ordering).
- The range is certified cETLus and ETL-Sanitation, meeting NSF/ANSI standards.
- The range is designed and built in the USA for lasting performance and easier parts availability.
What's Included:
- You can choose the style of the backsplash, such as stub back, 20-inch riser, or 20-inch riser with high shelf.
- Four 12-inch by 12-inch heavy-duty cast-iron top grates are included.
- A full-width removable drip/crumb pan is provided.
- An installation and operation manual is included.
Product Specs
| Specification | Value |
|---|---|
| Overall width | 24" (610 mm) |
| Overall depth | 32 1/2" (826 mm) |
| Cooking height | 36" (914 mm) on 6" legs |
| Total input | 100,000 BTU / 29.0 kW |
| Burners | 4 × 32,000 BTU open burners |
| Base | 20" space-saver storage cabinet |
| Gas connection | 3/4" NPT (rear) |
| Manifold pressure | Natural 5.0" W.C. | Propane 10.0" W.C. |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 2-year parts & labor (90-day replacement parts) |
| Shipping weight | Approx. 245 lb (111 kg) |
Features
| Specification | Value |
|---|---|
| Manufacturer | American Range |
| Certifications | cETLus, ETL-Sanitation, Made in USA |
| Height | 36.0in |
| Width | 24.0in |
| Depth | 32.5in |
| Shipping Weight | 260.0lbs |
| Exterior Finish | stainless steel front & sides |
| Top | (4) open burners |
| Vent | backriser with hi-shelf |
| Base | (1) cabinet |
| Specifications | Restaurant Range, gas, 24", (4) 32,000 BTU open burners, (1) 20" space saver storage base, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 29.0kW, 100,000 BTU, cETLus, ETL-Sanitation, Made in USA |
Purchase Notice
Pricing, availability, and product details are subject to change without notice. 24/7 Restaurant Equipment is not responsible for typographical errors or omissions. Freight charges may apply where applicable.
