Description
Channel Manufacturing 448S Specialty Storage & Transport
Product Description
The Channel CSS45PU is a durable and mobile single-section tray rack designed for demanding food-service environments. It can store, transport, and stage up to twenty 15" x 20" cafeteria trays with ease. The rack features end-loading capabilities and 6" slide spacing, measuring 23" wide, 30" deep, and 70" high.
Key highlights:
- The frame and slides are made of 18-gauge, 304 stainless steel, which is corrosion-resistant and NSF (National Sanitation Foundation) listed.
- The unit has (20) end-load slide levels with a 6-inch angle spacing, allowing for two trays per level.
- The 1-inch by 1-1/2-inch stainless steel angle slides are heli-arc welded to the frame, ensuring lifetime rigidity.
- The unit has 5-inch full-swivel, non-marking stem casters for smooth and quiet movement.
- The compact 23-inch wide footprint allows the unit to fit easily through standard doorways and aisles.
Built to perform:
- The vertical and horizontal supports are made of 1-inch square stainless steel tubing, providing exceptional torsional strength.
- The bottom-load ledge design simplifies the loading process while protecting the edges of the trays.
- The unit arrives fully assembled and ready for immediate use, thanks to its all-welded construction.
Ideal applications:
- School and university cafeterias where large quantities of food need to be prepared efficiently.
- Hospitals and healthcare facilities where patients and staff require nutritious and well-balanced meals.
- Corporate and institutional kitchens that serve a large number of employees or guests on a regular basis.
- Catering commissaries that need to produce large volumes of food for events, functions, and off-site dining.
Product Specs
| Specification | Value |
|---|---|
| Manufacturer / Model | Channel Manufacturing • CSS45PU (Stainless Series) |
| Tray capacity | 20 trays (15" × 20"), 2 trays per level |
| Slide spacing | 6" center-to-center |
| Overall dimensions | 70" H × 23" W × 30" D |
| Construction | 18-ga 304 stainless steel frame & slides |
| Load orientation | End-load |
| Casters | (4) 5" swivel stem, non-marking (2 with brakes optional) |
| Item weight | 56 lb (rack only) |
| Certifications | NSF Listed, Made in USA |
| Warranty | 5 years – manufacturer’s limited |
Features
| Specification | Value |
|---|---|
| Manufacturer | Channel Manufacturing |
| Certifications | NSF, Made in USA |
| Height | 70.0in |
| Width | 23.0in |
| Depth | 30.0in |
| Shipping Weight | 56.0lbs |
| Construction | stainless steel |
| Loading | end |
| Height (range) | 67" - 72" |
| Centers | 6" |
| Slide Capacity | 10 pair |
| Tray Size | 15" x 20" |
| Ships | welded |
| Specifications | Cafeteria Tray Rack, Single Section, Stainless Series, 23"W x 30"D x 70"H, Stainless Steel Construction, End Load, 6" Angle Spacing, (20) 15" x 20" trays, 5" Swivel Stem Casters model # CSS45PU, Made in USA, NSF, 56lbs. (ITEM WEIGHT ONLY), (2) trays per level, weight does not include 50 lbs. for pallet weight |
