Description
Continental Refrigerator DL1W Designer Line Heated Cabinets & Holding Shelves
Product Description
The Designer Line DL1W is a high-capacity hot food holding cabinet designed for busy kitchens. It features a self-contained heating system that circulates gentle, even air to maintain a precise 90 - 180 °F holding temperature range, using energy-efficient 3-inch insulation. With a slim 26-inch footprint, this cabinet easily fits into tight cooklines or plate pick-up areas without sacrificing interior capacity. The single-section cabinet offers 21 cubic feet of storage space across 3 shelves, with a narrow full-height door for easy access. To ensure proper ventilation, provide at least 12 inches of clearance above the cabinet and 3 inches on each side and rear.
Key Features:
- The heating unit is built into the top of the unit and uses a high-efficiency fan to circulate the air.
- The electronic controller has a bright digital display and can set off a high/low temperature alarm.
- The front is made of durable stainless steel, and the door is a narrow, full-height design. The sides and interior are lightweight aluminum.
- 3 inches of non-CFC polyurethane insulation helps retain heat and reduce energy costs.
- The self-closing door has cam-lift hinges and a magnetic Santoprene™ gasket to create a tight seal.
- Three heavy-duty chrome-plated shelves provide 20.4 square feet of total storage space, and the shelves are adjustable.
- A factory-installed cylinder lock helps secure the contents when the unit is not in use.
- The 6-inch stainless steel legs are adjustable, making it easy to clean the floor and level the unit.
- The unit is cETLus and NSF listed, ensuring it meets electrical safety and sanitation standards.
Popular Factory Options (sold separately):
- Your cabinet can come with automatic interior LED lighting, which provides bright and energy-efficient illumination.
- You can choose to have additional or stainless steel shelves installed, allowing for more storage space and a sleek, professional look.
- Pan slide assemblies are available, which can accommodate up to 19 trays, providing ample capacity for your needs.
- Casters can be added to your cabinet, making it easy to move and rearrange your workspace as needed.
- You can opt for a full stainless steel exterior or a stainless steel case back, giving your cabinet a durable and attractive finish.
Product Specs
| Specification | Value |
|---|---|
| Model | DL1W (Designer Line Warmer) |
| Capacity | 21 cu ft / 595 L |
| Exterior Dimensions (W × D × H) | 26 in. × 35 3/8 in. × 83 1/4 in.(660 mm × 899 mm × 2115 mm) |
| Shelf Count / Area | 3 shelves / 20.4 ft² |
| Temperature Range | 90 °F – 180 °F (32 °C – 82 °C) |
| Electrical | 208-230 V, 60 Hz, 1-phase, 7.2 A, 1500 W (hard-wired, no cord/plug) |
| Door Opening (W × H) | 19 3/8 in. × 58 5/8 in. |
| Construction | Stainless steel front & door / aluminum ends & interior, 3 in. foamed-in-place insulation |
| Approvals | cETLus, NSF |
| Shipping Weight | Approx. 284 lb (129 kg) |
Features
| Specification | Value |
|---|---|
| Manufacturer | Continental Refrigerator |
| Brand Name | Designer Line |
| Certifications | NSF, cETLus |
| Height | 83.25in |
| Width | 26.0in |
| Depth | standard depth |
| Shipping Weight | 284.0lbs |
| Interior Finish | aluminum interior |
| Exterior Finish | stainless steel & aluminum exterior |
| Size | 1 section |
| Interior configuration | shelves |
| Doors | hinged solid |
| Specifications | Designer Line Heated Cabinet, reach-in, one-section, (3) shelves, aluminum exterior & interior, stainless steel front & door, standard depth cabinet, narrow full-height door, electronic control with digital display, hi-low alarm, cETLus, NSF |
