Description
Delfield 8118-EFP LiquiTec Steam Tables & Food Wells
Product Description
This 1-pan, flush-mount, self-contained unit from Delfield uses eutectic fluid technology to keep your signature sides, salad toppings, or grab-and-go entrées ice-cold and easy to access. The LiquiTec® 8118-EFP delivers NSF-7 food-safe temperatures while sitting flush with your countertop, providing 100% cooling contact around the well. Larger 2- to 6-pan LiquiTec® models are also available. Contact us for lead-times, drawings, or customization assistance.
Why you'll love it:
- Eutectic Fluid Cooling: This provides 100% liner contact, which leads to faster temperature pull-down and more consistent temperatures compared to traditional wrap-around cooling systems.
- Flush-Mount Ergonomics: The 12" x 20" pans (available in 4" or 6" depth) sit flush with the counter, offering a sleek presentation and easy scooping for your customers.
- GreenGenius™ R290 Refrigeration: This ultra-efficient, environmentally-friendly hydrocarbon system uses only a 1/5 HP compressor, with zero ozone depletion potential (ODP) and zero global warming potential (GWP).
- Ready to Drop-In: The pre-installed press-fit gasket, 8-foot power cord, and NEMA 5-15P plug make installation a breeze.
- Built for the Long Haul: The all-stainless steel well and top, galvanized outer liner, and high-density foamed-in insulation ensure this unit will stand the test of time.
- Smart Control: The factory-set electronic temperature controller and expansion valve maintain temperatures between 33°F and 41°F, even in 86°F ambient conditions.
What's included:
- A stainless steel louver that can be installed on-site.
- A non-marking top gasket that fits snugly in place.
- An installation and operation manual to guide you through the setup process.
Popular factory options (sold separately):
- Flip-up sneeze guards that can be single or double-service
- Drain valve kit
- Remote refrigeration or compressor relocation
- 220 V / 50 Hz export electrical
Product Specs
| Specification | Value |
|---|---|
| Pan capacity | One 12" × 20" pan (4" or 6" deep, pans not included) |
| Counter cut-out | 17" W × 25" D (432 mm × 635 mm) |
| Overall well depth | 6.25" (159 mm) to drain |
| Refrigeration | Self-contained, R290, 1/5 HP compressor, 218 BTU load |
| Electrical | 115 V / 60 Hz / 1-Ph, 2.4 A, NEMA 5-15P cord & plug |
| Drain | ½" stainless drain with copper manifold |
| Certifications | cULus, NSF 7, R290 marking |
| Shipping weight | Approx. 180 lb (82 kg) |
| Warranty | 1 year parts & labor (standard) |
Features
| Specification | Value |
|---|---|
| Manufacturer | Delfield |
| Brand Name | LiquiTec |
| Certifications | NSF, UL |
| Height | 24.24in |
| Width | 18.2in |
| Depth | 26.0in |
| Shipping Weight | 180.0lbs |
| Finish | stainless steel top & inner liner, galvanized outer liner |
| Width (side - side) | 13 - 18 inches |
| Pan Qty | 1-pan |
| Style | self-contained refrigeration |
| Layout | deep |
| Insulation | insulated |
| Pan Size | full-size (12" x 20") |
| Specifications | LiquiTec® Drop-In Cool Food Unit, 1-pan size, 4" or 6" deep pans flush with counter top, insulated pan, stainless steel inner liner & top, galvanized outer liner, self-contained Eutectic fluid refrigerated system, R290 Hydrocarbon refrigerant, 1/5 hp, (17" x 25" cutout required), cUL, UL, NSF |
