Description
Delfield N8018 Steam Tables & Food Wells
Product Description
The Delfield N8018 ice-cooled cold pan keeps your salads, garnishes, beverages, and pre-chilled entrees at safe, appetizing temperatures without the need for electricity. This 18-inch by 26-inch pan fits neatly into a 17-inch by 25-inch counter cut-out, providing professional, food-safe cold holding even in compact serving lines. Please verify the cut-out size and local plumbing codes before installation. For more information on warranty and coverage, contact us.
Key Benefits:
- No power required - the ice-chilled design makes this perfect for use in mobile bars, salad stations, or outdoor venues.
- The 20-gauge stainless-steel top with a non-marring press-fit gasket creates a clean, flush mount that protects countertops.
- The 22-gauge stainless interior liner has an integral V-stamped pan rest for fast draining and easy pan loading.
- Includes a sectional, removable perforated false bottom to keep food pans above melt water.
- Ships with adapter bars to fit a full-size 12" × 20" pan, allowing you to use standard hotel pans you already own.
- High-density, CFC-free polyurethane insulation locks cold in and moisture out.
- The 1" plastic drain (field-installed) allows for quick ice melt removal and easy cleanup.
- The galvanized exterior housing adds strength while keeping the weight to just 37 lb.
Ideal Applications:
- Self-service salad and garnish bars where customers can easily access and serve themselves.
- Catering and banquet buffets, keeping the food fresh and chilled for guests.
- Concession kiosks and food trucks, providing a convenient way to chill bottled beverages.
- Back-bar areas, chilling bottled beverages to be served.
Product Specs
| Specification | Value |
|---|---|
| Model | N8018 |
| Pan Capacity | 1 × Full-size 12" × 20" pan (6" deep max) |
| Overall Dimensions (W × D) | 18" × 26" (46 cm × 66 cm) |
| Required Counter Cut-Out | 17" × 25" (43 cm × 64 cm) |
| Interior Depth | 10.75" (27 cm) |
| Drain Size | 1" (25 mm) plastic, field-installed |
| Construction – Top / Liner | 20-ga. stainless steel / 22-ga. stainless steel |
| Exterior Housing | 24-ga. galvanized steel |
| Insulation | High-density, eco-friendly polyurethane foam |
| Shipping Weight | 37 lb (17 kg) |
| Certifications | NSF-2 |
| Warranty | 1-year parts / 90-day labor |
Features
| Specification | Value |
|---|---|
| Manufacturer | Delfield |
| Certifications | NSF |
| Height | 10.75in |
| Width | 18.0in |
| Depth | 26.0in |
| Shipping Weight | 37.0lbs |
| Depth (front-to-back) OA | 25 - 30 inches |
| Width (side - side) OA | 13 - 18 inches |
| Layout | straight |
| Pan Qty | 1-pan |
| Exterior Liner | galvanized steel |
| Interior Liner | stainless steel |
| Specifications | Drop-In Ice Cooled Cold Pan, 18" W x 26" D, (1) 12" x 20" pan size, fit top gasket, removable perforated false bottom, insulated, 1" drain, stainless steel top & interior, galvanized exterior, (17" x 25" cutout required), NSF |
