Magikitch'n (Middleby) APM-SMB-672 Gas Charbroilers

Magikitch'n (Middleby) APM-SMB-672 Gas Charbroilers



Regular price $17,301.00
$17,301.00
Sale price
Regular price
Sale Sold out

From $328.72/week with



Need more information? Contact us today!

Magikitch'n (Middleby) APM-SMB-672 Gas Charbroilers

Product Description

The Magikitch'n APM-SMB-672 gas charbroiler delivers powerful 240,000 BTU/hr output in a compact, countertop-friendly design. Its ceramic coal heat and free-floating EZ-Tilt grate provide true char-grilled flavor, while the stainless steel construction ensures long-lasting durability. This high-production unit is perfect for kitchens with limited floor space, easily fitting onto a worktable or refrigerated base. Financing options are available through Middleby Equipment Financing for flexible payment plans.

Top Features:

  • The grill uses authentic ceramic coal briquettes that provide even heat distribution and create steak-house style sear marks.
  • The cooking surface is massive, measuring 1,704 square inches, and is fueled by 16 individual stainless-steel burners with front controls.
  • The free-floating, ½-inch round-rod grate is designed to resist warping, and the EZ-Tilt feature channels grease into the front trough to minimize flare-ups.
  • The low-profile 21-3/8-inch height allows the broiler to be comfortably placed on counters, chef bases, or equipment stands.
  • The double-wall, fully insulated cabinet is clad in stainless steel on all four sides, providing maximum heat retention and easy wipe-down cleaning.
  • The 6-inch stainless steel service shelf with a towel bar keeps seasonings, trays, and utensils within easy reach.
  • The 4-inch adjustable legs with bullet feet allow the unit to be leveled on uneven surfaces.
  • The runner-tube pilot system and single ½-inch gas connection simplify the installation process.
  • The grill includes a heavy-duty top-grid scraper for end-of-shift cleanup.
  • The grill has safety and sanitation certifications, including CSA Flame, CSA Star, and NSF.

Included With Your Broiler:

  • The broiler comes with a round-rod top grate that can move freely.
  • It includes a 6-inch stainless steel service shelf with a towel bar.
  • A top grid scraper is provided to help clean the grill.
  • Three removable crumb trays are included for easy cleaning.
  • The broiler has adjustable 4-inch bullet-style legs.
  • A ¾-inch gas pressure regulator (loose) is also included.

Popular Options & Accessories:

  • High-output burner package that adds 80,000 BTU/hr of heating power.
  • MagiKrome or cast-iron grates in standard or fish spacing configurations.
  • MagiGriddle plate for versatile flat-top cooking.
  • Side/back extensions or a slip-on stainless steel cover.
  • 48-inch quick-disconnect hose and restraint kit.
  • Equipment stand with an undershelf for additional storage.

Product Specs

Specification Value
Model APM-SMB-672 (Ceramic Coal)
Total BTU/hr (Natural or LP) 240,000 (Standard) | 320,000 (High-Output option)
Burners 16 stainless-steel, individually controlled
Cooking Area 1,704 in² (11,001 cm²)
Overall Dimensions (W × D × H) 72″ × 35-1/2″ × 21-3/8″ (183 × 90 × 54 cm)
Gas Connection Single ¾″ NPT (regulator supplied loose)
Manifold Pressure Natural 7-10″ WC | LP 11-13″ WC
Shipping Weight 1,050 lb (476 kg)
Approvals CSA Flame, CSA Star, NSF
Warranty 2-year parts & labor, factory-authorized service network

Features

Specification Value
Manufacturer Magikitch'n (Middleby)
Certifications NSF, CSA Star, CSA Flame
Height 21.5in
Width 72.0in
Depth 35.5in
Shipping Weight 1050.0lbs
Width (side - side) OA 67 - 72"
Control Type manual controls
Heating Source ceramic
Specifications Coal Charbroiler, low profile countertop, gas, 72"W x 35-1/2"D x 21-1/2"H overall size, free floating round rod top grate with EZ tilt to front grease trough, ceramic briquettes, stainless steel on all sides, 6" service shelf, top grid scraper, 4" legs with bullet feet, CSA Flame, CSA Star, NSF
