Description
Continental Refrigerator D2FENSAPTHD Designer Line Reach-In Refrigerators & Freezers
Product Description
Model D2FENPTHD | 2-Section | Half-Height Solid Doors
The Continental Refrigerator Designer Line Pass-Thru Freezer is built for high-volume kitchens that require fast, two-way access to frozen product. It delivers NSF-7 performance even in 100 °F ambient conditions. With a top-mounted "plug" refrigeration system, all-stainless exterior, and intuitive digital controls, this freezer keeps food safe, staff efficient, and your operation looking its best.
Why You'll Love It:
- The pass-through design allows you to load from the prep side and pull from the cook or service side without breaking the cold chain.
- The four half-height doors reduce cold air loss while providing full-width storage access.
- The unit is factory set at 0 °F (adjustable to -10 °F) and maintained by a 1 HP, self-contained R-290 refrigeration system.
- The electronic controller features a digital temperature read-out, high/low temperature alarm, and automatic electric defrost.
- The interior is illuminated by LED lighting and includes 6 epoxy-coated shelves providing 40.8 sq ft of usable storage space.
- The durable construction features a stainless steel exterior, aluminum interior, and 3" CFC-free foamed-in insulation.
- The field-removable refrigeration "plug" and upper side panels make future service or installation in tight spaces easier.
- The secure storage includes magnetic door gaskets, self-closing cam-lift hinges, and factory-installed cylinder locks.
- The adjustable 6" stainless steel legs meet sanitation codes and simplify floor cleaning.
Product Specs
| Specification | Value |
|---|---|
| Capacity | 52 cu ft / 1472 L |
| Exterior / Interior | Stainless steel / Aluminum |
| Overall Dimensions (W × D × H) | 57" × 35 3⁄8" × 83 1⁄4" (incl. legs) |
| Depth (doors open 90°) | 58" |
| Doors | 4 half-height, solid, self-closing with locks |
| Shelves | 6 epoxy-coated steel, adjustable |
| Operating Temp | 0 °F to -10 °F |
| Refrigerant | Natural R-290 |
| Compressor | 1 HP, top-mounted |
| BTU/hr Capacity | 2,470 BTU (at +25 °F evap., 90 °F ambient) |
| Defrost | Automatic electric with hot-gas condensate removal |
| Electrical | 115 V / 60 Hz / 1-ph, 9.7 A, NEMA 5-15P cord & plug |
| Certifications | cETLus, NSF |
| Warranty | 7 years parts, labor & compressor (U.S. & Canada) |
Features
| Specification | Value |
|---|---|
| Manufacturer | Continental Refrigerator |
| Brand Name | Designer Line |
| Height | 87.25in |
| Width | 57.0in |
| Depth | 39.0in |
| Shipping Weight | 760.0lbs |
| Door Style | half door(s), wide |
| Refrigeration | self-contained, top mounted |
| Door Type | solid |
| Compressor HP | 3/4 HP |
| Size | 2 section |
| Exterior Finish | all stainless steel exterior |
| Specifications | Designer Line Wide Freezer, pass-thru, 57"W, two-section, self-contained refrigeration, stainless steel exterior, aluminum interior, standard depth cabinet, wide half-height solid doors, cylinder locks, electronic control with digital display, hi-low alarm, 6" stainless steel legs, 1 HP, cETLus, NSF |
