Description
T&S Brass B-0117 Commercial Faucets & Plumbing
Product Description
Engineered for today's water-conscious commercial kitchens, the T&S B-0117 deck-mount single-hole mixing faucet pairs a space-saving design with a retractable pre-rinse arm that reaches every corner of the sink before tucking neatly out of the way. Its WaterSense-certified 0.65 GPM spray valve cuts water and energy use without sacrificing cleaning power, while heavy-duty brass and stainless-steel construction stand up to years of daily abuse. T&S offers a full line of interchangeable components, allowing you to customize the B-0117 to your exact application.
Key features:
- The faucet has a polished chrome-plated brass body and a single-hole deck-mount design.
- The retractable swivel arm provides a 21 15⁄16″ reach and a 29 ¼″ maximum pull-down clearance.
- The water-saving 0.65 GPM B-0107-C spray valve is EPA WaterSense and 2019 DOE PRSV – Class II certified.
- The quarter-turn Eterna cartridges have integral spring checks to prevent cross-flow and simplify maintenance.
- The heat-resistant gray grip with a hold-down ring allows for continuous-spray operation.
- The 6″ wall bracket adds stability to the assembly.
- The 20″ flexible stainless-steel pre-rinse hose and 18″ braided stainless-steel supply lines (½″ NPSM / ⅝″ compression) are included.
- The EasyInstall™ lock-nut and bushing speed up installation on a single 1½″ mounting hole.
- The lead-free design meets NSF 372 requirements.
Performance & compliance:
- The flow rate is 0.65 gallons per minute (GPM) at 60 pounds per square inch (psi) of water pressure.
- The operating pressure range is between 20 and 125 psi.
- The water temperature range is from 40 degrees Fahrenheit (°F) to 140 °F (4 degrees Celsius (°C) to 60 °C).
- The product is certified to meet the ASME A112.18.1 / CSA B125.1 standards.
- The product is compliant with the NSF 61 and NSF 372 low-lead requirements.
- The product is compliant with the EPA WaterSense and EPAct 2005 regulations.
- The product is classified as 2019 DOE PRSV – Class II.
- The manufacturer provides a one-year limited warranty.
Product Specs
| Specification | Value |
|---|---|
| Overall height – normal hanging | 42 13⁄16″ (1 088 mm) |
| Maximum pull-down clearance | 29 ¼″ (743 mm) |
| Overhang / reach | 21 15⁄16″ (557 mm) |
| Mounting hole required | 1 ½″ (38 mm) diameter |
| Maximum deck thickness | 1 ⅞″ (48 mm) |
| Wall bracket length | 6″ (152 mm) |
| Pre-rinse hose length | 20″ stainless steel |
| Supply lines | 18″ braided stainless steel (hot & cold) |
Features
| Specification | Value |
|---|---|
| Manufacturer | T&S Brass |
| Shipping Weight | 14.12lbs |
| Valve Type | compression valves |
| Wall or Deck Mount | deck mount |
| Faucet Centers | single hole centers |
| Specifications | Pre-Rinse Unit, deck mount, single hole mixing faucet, low flow 0.65 GPM spray valve (B-0107-C), retractable arm assembly, 29-1/4" max pull down position, 44" flexible stainless steel hose, 18" flexible supply lines, 6" wall bracket, quarter-turn Eterna cartridges, low lead, 2019 DOE PRSV - Class II |
