Description
Univex DOME47S Coal/Wood Fired Ovens
Product Description
The Univex DOME47S pizza oven offers exceptional performance and versatility. Its 47 1/4" round cooking chamber can bake up to seven 12" pizzas at once, powered by a 92,500 BTU gas-fired system. Handcrafted with genuine firebrick and heavy insulation, this oven delivers the intense heat of a traditional wood-fired oven without the need for wood. The cool-touch exterior makes the Univex DOME47S a stunning centerpiece for open kitchens, food trucks, and pizzerias.
Key Features:
- It can hold seven 12-inch pizzas at once, making it ideal for high-volume service.
- The static firebrick floor radiates even heat, which helps create crisp, leopard-spotted crusts.
- The powerful 92,500 BTU gas burner (natural or LP) has a simple 3/8" NPT hookup.
- The multi-layer insulation keeps the exterior safe to touch, even at peak temperature.
- It ships ready to use, with an iron stand, iron door, built-in thermometer, and internal 7 ⅞" stack exhaust included.
- It can be plugged into any kitchen with a 115 V / 1 ph / 16 A electrical connection for ignition and controls.
- It is cCSAus & NSF certified for gas safety and sanitation.
Built for Performance:
- Each oven is handcrafted and individually assembled by skilled artisans, ensuring unmatched thermal mass and durability.
- Dense insulation allows for a cool-touch construction, enabling you to install the oven closer to guests for an impressive, front-of-house baking experience.
- In many jurisdictions, this oven can be direct-vented, eliminating the need for a high-CFM exhaust fan.*
- Customize the exterior with a variety of optional finishes, such as brick, tile, marble, or mosaic, to complement any décor.
Product Specs
| Specification | Value |
|---|---|
| Model | DOME47S (Square) |
| Internal cooking diameter | 47 ¼″ / 120 cm |
| 12″ pizza capacity | 7 pizzas |
| Heat source | Gas (Natural 4.0″ WC or Propane 10.0″ WC) |
| Input rate | 92,500 BTU/hr |
| Gas connection | 3/8″ (.95 cm) NPT |
| Electrical | 115 V • 60 Hz • 1 ph • 16 A |
| Vent pipe | 7.87″ / 200 mm (internal stack supplied) |
| Exterior (W × D × H) | Approx. 64.9″ × 55.1″ × 72.8″ (165 × 140 × 185 cm) |
| Shipping weight | ≈ 4,850 lb / 2,200 kg |
| Certifications | NSF, cCSAus |
| Warranty | 1-year on-site parts & labor |
Features
| Specification | Value |
|---|---|
| Manufacturer | Univex |
| Certifications | NSF, cCSAus |
| Height | 72.8in |
| Width | 64.9in |
| Depth | 62.9in |
| Shipping Weight | 4850.2lbs |
| Interior Deck Construction | stone |
| Fuel Type | gas-fired |
| Base Style | stationary (stand base) |
| Shape | round |
| Hearth Width / Diameter | 40" - 49" |
| Specifications | Artisan Stone Hearth Square Pizza Oven, gas, (7) 12" pizza capacity, round 47-1/4" diameter internal cooking chamber, includes: thermometer, internal stack exhaust, iron stand & door, insulated, handmade firebrick, 115v/60/1-ph, 16 amps, 92,500 BTU, cCSAus, NSF |
