Description
Vollrath 3664420HD Steam Tables & Food Wells
Product Description
Maximize storage in tight spaces with Vollrath's 4-Pan Short-Side Modular Hot Drop-In. Featuring marine-grade stainless steel and 12" x 20" sideways-turned wells, this compact unit accommodates four full-size pans within an 18"-deep footprint. Thick polyurethane insulation and thermostatic controls maintain optimal serving temperatures for all your menu items.
Why You'll Love It:
- The unit has a narrow 18-inch counter depth, allowing it to fit in tight spaces while still providing full-size pans that are easy to reach.
- The top and exterior housing are made of corrosion-proof, marine-grade stainless steel, ensuring long-lasting durability.
- Four independent, thermostatic controls with indicator lights allow you to precisely maintain the desired holding temperatures.
- The 1-inch copper manifold drain with a master shut-off and included drain plug makes for quick and easy clean-up.
- The full-perimeter drip edge and included gasket protect your countertops from condensation.
- Thick polyurethane foam insulation on every side and between the wells maximizes energy efficiency.
- The unit comes ready to plug in, with a 6-foot cord and NEMA 5-30P plug, eliminating the need for hard-wiring.
- The zero-clearance installation and standard mounting clips make it suitable for counters up to 3 inches thick.
Product Specs
| Specification | Value |
|---|---|
| Pan capacity | 4 full-size 20" × 12" (sideways) |
| Total power | 2,500 W (625 W per well) |
| Controls | 4 thermostatic knobs, remote stainless panel (4' tether) |
| Voltage / Phase | 120 V / 60 Hz / 1-ph |
| Amps / Plug | 20.8 A | NEMA 5-30P |
| Well size (each) | 20" × 12" × 8" deep |
| Overall dimensions | 88-1/4" L × 18" W |
| Counter cut-out | 87-1/2" L × 17-1/4" W | 7/8" corner radius |
| Drain | 1" copper manifold with master ball valve; drain plug included |
| Construction | 18 ga / 316 marine-grade stainless steel top, stainless exterior housing |
| Certifications | UL, CUL, NSF |
| Warranty | 2 years (see VollrathFoodservice.com for full policy) |
Features
| Specification | Value |
|---|---|
| Manufacturer | Vollrath |
| Certifications | NSF, UL, Made in USA |
| Height | 21.5in |
| Width | 88.56in |
| Depth | 18.0in |
| Shipping Weight | 173.0lbs |
| Pan Capacity | (4) full size (12" x 20") |
| Style | individual pans |
| Controls | thermostatic controls |
| Drain | with drain |
| Construction | stainless steel construction |
| Wet or Dry operation | wet |
| Insulated or Non-Insulated | insulated |
| Specifications | Short Sided Hot Well, Drop-In, (4) pan, thermostatic controls, manifold drains, 2500 watts, 120v/60/1-ph, 20.8 amps, NEMA 5-30P, turns full size pans sideways for more narrow presentation & easy reach, 18 gauge/316 marine grade stainless steel top, stainless steel exterior housing, thick polyurethane foam insulation, full perimeter drip edge, drain plug included, overall dimensions 88-1/4" x 18", cutout dimensions 87-1/2" x 17-1/4", 7/8" corner radius, well size 20" x 12" with 8" deep well, UL, CUL, NSF, Made in USA (Refer to vollrathfoodservice.com for full warranty policy) |
