Description
American Range AR-3RB-SB Gas Ranges
Product Description
American Range's 36-inch AR-3RB-SB provides powerful 90,000 BTU performance with manual controls, all made right here in the USA. This heavy-duty restaurant range features a high-performance radiant charbroiler top paired with a spacious under-cabinet storage base, delivering the grilling power your kitchen needs without sacrificing valuable floor space.
Key Features:
- The broiler deck is 36 inches wide and powered by six 15,000 BTU steel burners, providing a total of 90,000 BTUs.
- Cast-iron radiants and extra-thick cast-iron grates ensure even heat distribution and create bold sear marks on your food.
- Each of the six burners has a manual gas valve and pilot, allowing you to create up to six independent heat zones.
- The full-width, removable drip pan makes for quick and easy cleanup without the need for tools.
- The 26 ½-inch stainless steel storage base can hold hotel pans, sheet trays, or dry goods right under the grill.
- The all-stainless front, sides, 6-inch stub back, and 6-inch deep landing ledge are built to withstand daily use.
- The 6-inch chrome-plated adjustable legs provide a 38-inch cooking height, and optional casters are available.
- The grill is field-convertible for use with Natural or LP gas, with a 3/4-inch rear NPT connection and regulator.
- The grill is cETLus and ETL-Sanitation listed, ensuring it meets gas safety and food-service hygiene standards.
Product Specs
| Specification | Value |
|---|---|
| Model | AR-3RB-SB |
| Equipment type | Radiant broiler range w/ storage base |
| Overall width | 36" / 914 mm |
| Depth (incl. stub back) | 32 ½" / 825 mm |
| Cooking height | 38" / 965 mm |
| Burners | 6 × 15,000 BTU steel tube |
| Total input | 90,000 BTU/hr (27 kW) |
| Manifold pressure | Natural 5.0" W.C. • LP 10.0" W.C. |
| Gas connection | 3/4" NPT (rear, regulator included) |
| Clearances to combustibles | 12" sides • 4" rear (0" to non-combustibles) |
| Certifications | cETLus, ETL-Sanitation |
| Warranty | 2-year parts & labor (broiler burners, grates & radiants 90 days) |
Features
| Specification | Value |
|---|---|
| Manufacturer | American Range |
| Height | 56.0in |
| Width | 36.0in |
| Depth | 32.25in |
| Shipping Weight | 570.0lbs |
| Exterior Finish | stainless steel front & sides |
| Base | (1) cabinet |
| Vent | stub back |
| Top | (1) charbroiler |
| Specifications | Restaurant Range, gas, 36", charbroiler, cast iron radiants, reversible top grates, manual controls, (1) 26 1/2" storage space, stainless steel front, sides & 6" stub back, 6" chrome plated legs, 27.0kW, 90,000 BTU, cETLus, ETL-Sanitation, Made in USA |
