American Range AR-4B-24RG-CL-SBR Gas Ranges

Product Description

The American Range Model AR-4B-24RG-C-SB is a high-performance, 48-inch cooking solution made in the USA. It combines powerful open burners, a versatile raised griddle/broiler, and a convection oven, all within a durable stainless-steel cabinet. Designed for high-volume kitchens, this workhorse delivers 198,000 BTU of cooking power to meet the demands of speed, power, and longevity. For more details on warranty and coverage, please contact the manufacturer.

Why You'll Love It:

  • The appliance features four 32,000 BTU open burners on the left, each with 12" x 12" cast-iron grates and a removable drip pan for easy cleaning.
  • The 24" raised griddle/broiler on the right has a ¾" steel plate, two 20,000 BTU burners, and a 3" grease trough for efficient cooking and easy maintenance.
  • The 26-½" convection oven on the left has a 30,000 BTU burner, a porcelain interior, 2 chrome racks, and 5 rack positions for versatile cooking options.
  • The 11" storage base under the griddle provides convenient storage for sheet pans, griddle tools, or hotel pans.
  • The appliance features an all-stainless steel exterior front and sides, plus a 6" deep landing ledge for plating and handling pans.
  • You can choose from three different backguard options: a 6" stub back, a 20" riser, or a 20" riser with a high shelf, with no additional charge.
  • The appliance has 6" adjustable chrome-plated legs, and casters are available as an optional feature.

Built to Take the Heat:

  • The heavy-duty cast-iron burner heads are designed to resist clogging, ensuring reliable performance.
  • The burner knobs are made with a cool-touch, high-temperature material, providing safety for the operator.
  • The porcelain-enameled oven cavity and door liner are easy to wipe clean, making nightly cleanup a breeze.
  • The oven door is spring-assisted and counter-weighted, requiring no adjustments for a smooth and effortless operation.
  • The full-width, removable drip pan simplifies the nightly cleaning process.

Product Specs

Specification Value
Total Input 198,000 BTU /hr (58.0 kW)
Open Burners (4) × 32,000 BTU lift-off burners
Griddle/Broiler 24" W • (2) × 20,000 BTU burners • ¾" thick plate • manual valves
Convection Oven 30,000 BTU burner • 250°–500 °F thermostat • fan-assisted
Interior Oven Size 26-½" W × 22-½" D × 13-½" H
Gas Connection ¾" NPT (5.0" W.C. Natural • 10.0" W.C. LP)
Dimensions (W×D×H) 48" × 32-½" × 36"-44" (to cook surface/backguard)
Certifications cETLus • ETL Sanitation
Origin Designed & Built in the USA

Features

Specification Value
Manufacturer American Range
Certifications cETLus, ETL-Sanitation, Made in USA
Height 56.0in
Width 48.0in
Depth 32.25in
Shipping Weight 590.0lbs
Base (1) convection oven, (1) cabinet
Plate Thickness .750" = 3/4"
Exterior Finish stainless steel front & sides
Vent backriser with hi-shelf
Top (4) open burners, (1) 24" griddle/broiler
Specifications Restaurant Range, gas, 48", (4) 32,000 BTU open burners, (1) 24" raised griddle/broiler on right, 3/4" thick plate, manual controls, (1) 26-1/2" convection oven on left, (2) racks, (1) 11" storage base on right, stainless steel front, sides, choice of high shelf and riser, 20" riser or 6" stub back, 6" adjustable chrome plated legs, 58.0 kw 198,000 BTU, cETLus, ETL-Sanitation, Made in USA
