American Range AR60-48G2OB Gas Charbroilers

Product Description

Countertop – 184,000 BTU - Made in USA Elevate your kitchen with this versatile 48" griddle that combines the power of two high-efficiency open burners. Engineered and manufactured in California, this heavy-duty unit delivers even heat, fast recovery, and the durability that food-service professionals trust. With a clearance of 0" to non-combustible surfaces, it can be installed next to combustible walls, maintaining 12" (305 mm) at the sides and 4" (102 mm) at the rear. A compliant commercial ventilation system is required.

Key Features:

  • The griddle is 48 inches wide and made of 1-inch thick polished steel, which provides excellent heat retention and recovery.
  • The griddle has 4 U-shaped burners, each providing 30,000 BTUs, spaced 12 inches apart to ensure consistent surface temperatures.
  • The unit also has 2 open burners that provide 32,000 BTUs each, suitable for sautéing, cooking in stock pots, and finishing dishes.
  • The manual, infinite-adjust valves have easy-grip knobs for precise temperature control.
  • The 3-inch wide stainless steel grease trough and large removable grease pan make cleanup easy.
  • The stainless steel front, sides, and splash guards are durable and resist dents and corrosion.
  • Adjustable 4-inch stainless steel legs allow the unit to be leveled on any counter.
  • The appliance is ETL Listed and ETL-Sanitation certified for commercial use.

Perfect For:

  • Diners and short-order counters that need a reliable and efficient cooking solution.
  • Food trucks and concession trailers that require a versatile and portable griddle.
  • Breakfast, brunch, and all-day cafés that want to expand their menu options.
  • Steakhouses, pubs, and taprooms that need additional griddle space to handle increased demand.

Product Specs

Specification Value
Total input 184,000 BTU (54.0 kW)
Griddle burners 4 × 30,000 BTU U-burners
Open burners 2 × 32,000 BTU cast-iron burners
Cooking surface 48" W × 21" D griddle + 12" W open burner section
Controls Manual valves (no electrical connection required)
Gas type Natural or Propane (field convertible), 3/4" NPT rear manifold
Manifold pressure 5.0" W.C. Natural | 10.0" W.C. Propane

Features

Specification Value
Manufacturer American Range
Certifications ETL-Sanitation, Made in USA
Height 13.0in
Width 60.0in
Depth 32.0in
Shipping Weight 787.0lbs
Open Burners 2
Plate Thickness 3/4"
Griddle Controls manual controls
Width (side - side) OA 60"
Griddle Area 48"W x 20"D
Griddle Plate Finish smooth steel
Specifications Griddle/Open Burner Combination, gas, 60", countertop, (1) 48" griddle with 1" thick plate, 4" legs, manual controls, (2) 32,000 BTU open burners, 3" wide grease trough & pan, stainless steel front & sides, 54.0kW, 184,000 BTU, ETL-Sanitation, Made in USA
