Description
Vollrath 3640980HD Steam Tables & Food Wells
Product Description
Model 3640970HD, 208V, Thermostatic, NEMA 6-30P. Built for relentless commercial use, this made-in-USA drop-in keeps six full-size pans of soup, entrées, or sides at safe, appetizing temperatures. Marine-grade stainless steel, individual thermostatic controls, and an automatic water-fill system provide consistent results with minimal labor.
Key features & benefits:
- The unit has six independent wells, each measuring 12 x 20 inches, made from durable 20-gauge 316 marine-grade stainless steel for maximum corrosion resistance.
- The auto-fill system automatically maintains the optimal water level, preventing dry-well burnout.
- Each well has individual thermostatic controls with power lights, allowing you to set the temperature for each menu item separately.
- The wet operation meets NSF 4 performance standards, providing even, gentle heat.
- The 1-inch copper manifold drain with a master valve and ball valves on every well enables fast and mess-free cleanup.
- The drip-free perimeter flange and supplied gasket protect the counter from spills.
- The unit is fully insulated, including between wells, to lower energy costs and keep the exterior surfaces cool.
- The heavy-duty 18-gauge stainless steel top and stainless steel exterior housing are built to withstand daily use.
- The unit ships ready to install, with a 6-foot cord and plug, positioning clips for counters up to 3 inches thick, and a 3-foot tethered control panel.
Perfect for:
- Serving food efficiently in cafeteria and buffet lines
- Catering to the needs of hotels, casinos, and cruise ships
- Providing meals in corporate dining facilities and convenience stores
- Preparing high-volume meals in commissary kitchens
Product Specs
| Specification | Value |
|---|---|
| Number of wells | (6) full-size 12 × 20 in pans — up to 6 in deep |
| Construction | 20 ga 316 SS wells, 18 ga SS top, stainless exterior housing |
| Heat type | Wet operation only (water required) |
| Controls | (6) thermostatic dials with indicator lights — remote panel, 3 ft tether |
| Auto-fill | Integrated, water connection required |
| Total power | 6,000 W (625 W per well) |
| Electrical | 208 V / 60 Hz / 1-phase • 18 A • 6 ft cord with NEMA 6-30P |
| Overall dimensions | 81 1⁄4 W × 26 D × 21 1⁄2 H in (206.4 × 66 × 54.6 cm) |
| Counter cut-out | 80 1⁄2 W × 25 1⁄4 D in (204.5 × 64.1 cm) — 7⁄8 in corner radius |
| Drain | 1 in copper manifold (½ in MPT outlet) with individual well shut-offs & master valve |
| Certifications | NSF 4, cULus Listed, Made in USA |
Features
| Specification | Value |
|---|---|
| Manufacturer | Vollrath |
| Certifications | NSF, cULus, Made in USA |
| Height | 21.5in |
| Width | 81.25in |
| Depth | 26.0in |
| Shipping Weight | 211.0lbs |
| Style | individual pans |
| Construction | stainless steel construction |
| Pan Capacity | (6) full size (12" x 20") |
| Drain | with drain |
| Controls | thermostatic controls |
| Insulated or Non-Insulated | insulated |
| Wet or Dry operation | wet |
| Specifications | Hot Food Well Unit, Drop-In, electric, (6) 12" x 20" individual 20 gauge/316 marine grade stainless steel insulated wells, 81-1/4"W x 26"D x 21-1/2"H (overall), wet operation only, auto-fill, individual thermostatic controls mounted in panel with cord, power indicator light, drip-free flange, 1" copper manifold drain with individual well shutoffs & manifold shutoff, 18 gauge stainless steel top, stainless steel exterior housing, includes positioning clips, 6000 watts, 208v/60/1-ph, 18.0 amps, cord with NEMA 6-30P, NSF, cULus, Made in USA (80-1/2"W x 25-1/4"D cutout size, requires 7/8" corner radius) (Refer to vollrathfoodservice.com for full warranty policy) |
